WBN-SC2458X15i65WF
WBN-SC2458X15i65WF
Multi-band Panel
2400~2500 5150~5850
Dual Polarization
X X
Half-power Beam Width
65° 65°
Fixed Electrical Downtilt
0° 0°
2400~2500 5150~5850
Dual Polarization
X X
Half-power Beam Width
65° 65°
Fixed Electrical Downtilt
0° 0°
| Electrical specifications | WBN-SC2458X15i65WF | ||
| Frequency range (MHz) | 2400～2500 | 5150～5850 | |
| Polarization | ±45° | ||
| Gain (dBi) | 2×1 4.5 | 2×14.5 | |
| Electrical Downtilt (°) | 0 | ||
| Half-power beam width (°) | Horizontal:65 Vertical:15 |
Horizontal:65 Vertical:15 |
|
| Front-to-back ratio (dB) | ≥20 | ||
| Cross-polar discrimination (dB) | ≥15 | ||
| Isolation (dB) | ≥28 | ||
| Impedance (Ω) | 50 | ||
| VSWR | ≤1.5 | ≤2 | |
| Maximum power (W) | 200 | 50 | |
| Lighting protection | DC Ground | ||
| Mechanical specifications | ||
| Connector | 4×N Female | |
| Connector position | Bottom | |
| Height/width/depth (mm) | 500×167×55 | |
| Packing size (mm) | 600×220×125 | |
| Weight (kg) | 2 | |
| Radome material | UPVC | |
| Radome color | Gray | |
| Mechanical tilt (°) | 0~15 | |
| Operating temperature (℃) | -40~60 | |
| Rated wind velocity (m/s) | 60 | |
| Suitable pole diameter (mm) | 40~75 | |
| Mounting kit | JM-2400RZ1 | |
